Nominal Power: 110W
Maximum Power Voltage: 19.05V
Nominal Power: 110W
Maximum Power Voltage: 19.05V
| Model number | SZBC-110 |
| Nominal Power | 110W |
| Cell Efficiency | ＞25% |
| Maximum Power Current | 5.78A |
| Maximum Power Voltage | 19.05V |
| Open-circuit Voltage | 21.75V |
| Short-circuit Current | 6.13A |
| Maximum System Voltage | 500V |
| Output Tolerance | 0~+3% |
| Cable （MC4） | 700mm / 2.5mm² |
| Module Structure | Aluminum Frame / Glass / EVA /Backsheet |
| Junction box rating | ≥IP67 |
| Cell | 182*91.875–10*3 |
| Working Temperature | -40~+85℃ |
| Module Dimensions | 950*580*30mm |
| Weight（Net /Gross） | 4.55/5.4kg |
