TOPCon-N--110W (1080*510*30mm) Rigid Solar panel SOLARFAM

Dimensions : 1080x510x30mm

Weight : 6.2 kg

Nominal Power: 110W

Maximum Power Voltage: 19.14V




Advantages of N-type ToPcon Cells

1. The battery has high conversion efficiency, excellent interface passivation and carrier transport capabilitiesand high VOC and FF

2. Excellent parameter performance: lt has the advantages of a high bifacial ratio, low attenuation, low-temperature coefficient, and good low-light effect.

3. The process equipment production line has high compatibility and is compatible with high-temperature preparation process production lines of PERC and N-PERT bifacial cells.

4. N-type TOPCon batteries can be combined with SE, lBC, multi-busbar, half-chip, and lamination technologies to significantly improve battery efficiency and module power.

5.Using tempered glass, high transparency.

6. Anti-corrosion EVA effectively protects the battery panel

7. Strong and anti-wind and snow, unique technology to avoid freezing of water in the frame and deformation.

8. Lightweight and flexible features can make it seamlessly integrated into your vehicle.

9. Packed in a single carton, with protective corners on all four corners

10. OEM and ODM supported.

Model numberSZ-110-M
Nominal Power110W
Cell Efficiency≥22%
Maximum Power  Current5.75A
Maximum Power Voltage19.14V
Open-circuit Voltage22.44V
Short-circuit Current6.10A
Maximum System Voltage500V
Output Tolerance0~+3%
Cable MC4700mm / 2.5mm²
Module StructureAluminum Frame / Glass / EVA /Backsheet
Junction box rating≥IP67
Cell160*93.5–11*3
Working Temperature-40~+80℃
Module Dimensions1080*510*30mm
WeightNet /Gross6.2/7.1kg
