170W (1230*670*30mm, White) Frame Solar panel SOLARFAM

Dimensions : 1230x670x30mm

Weight : 8.9 kg

Nominal Power: 170W

Maximum Power Voltage: 23.82V




Advantages

The efficiency of high-quality and high-efficiency monocrystalline silicon wafers can reach 22%Using tempered glass, high transparency.

Anti-corrosion EVA effectively protects the battery panel.

Strong and anti-wind and snow, unique technology to avoid freezing of water in the frame and deformation.

Lightweight and flexible features can make it seamlessly integrated into your vehicle.

Packed in a single carton, with protective corners on all four corners.

OEM and ODM supported.


Scope of application

Prevent the loss of electricity:used on the roofthe car, charge the car battery at anytime. Can prevent the car battery from losing electricity, and solve the situation that the car cannot be fired due to the battery loss caused by the long-term parking of the vehicle.

On-board electrical appliances: when using on-board electrical appliances, the original power of the car battery will not lose (car audio, navigator,driving recorder, exhaust fan, car blower, car refrigerator, cell phone, etc.

Experimental power generation:DlY experiments for schools.


Model numberSZ-170-S
Nominal Power170W
Maximum Power  Current7.14A
Maximum Power Voltage23.82V
Open-circuit Voltage28.31V
Short-circuit Current7.57A
Maximum System Voltage500V
Output Tolerance0~+3%
Cable MC4700mm / 2.5mm²
Module StructureAluminum Frame / Glass / EVA /Backsheet
Junction box rating≥IP67
Cell210*28.2–42*3
Working Temperature-40~+80℃
Module Dimensions1230*670*30mm
WeightNet /Gross8.9/10.0kg
