AST-5160 51.2V 60AH Lithium Battery

The AST-5160 is a high-performance 51.2V 60Ah lithium battery pack with 3072Wh usable energy, built with an integrated smart BMS for reliable energy storage. Designed for stable power supply, it balances high continuous output and safe charging & discharging performance, ideal for off-grid and backup power scenarios.

Core Features & Advantages

✅ Integrated Smart BMS Protection The built-in Battery Management System continuously monitors cell voltage, temperature and current. It provides full protection against overcharge, over-discharge, over-current, short circuit and overheating, extending battery lifespan and ensuring safe operation.

✅ Strong & Stable Power Output Supports up to 100A continuous discharge current and 120A peak discharge current. It delivers steady high power to handle heavy loads, meeting high instantaneous power demand.

✅ Flexible Charging Performance 30A recommended charging current for daily use, while supporting 120A maximum charge current for fast-charging needs. Precise voltage cut-off design protects cells during the whole charging cycle.

✅ High Energy Density & Compact Size 3072Wh energy capacity within a compact 410×280×180mm cabinet. Saves installation space and easy for transport and mounting.

✅ Long Service Life & Low Maintenance Lithium chemistry delivers far longer cycle life compared with lead-acid batteries. No regular water filling or maintenance required, reducing your long-term operation cost.

Applications

· Off-grid solar energy storage systems

· RV, campervan and marine yacht power supply

· Home backup power & emergency power supply

· Commercial off-grid power stations

· Telecom base station backup power

· Industrial mobile equipment power

· Model: AST-5160

· Nominal Capacity: 60Ah / 3072Wh

· Nominal Voltage: 51.2V

· Recommended Max Charge Current: 30A

· Peak Charge Current: 120A

· Peak Discharge Current: 120A

· Max Continuous Discharge Current: 100A

· Charge Cut-off Voltage: 58.4V (Pack) / 3.65V (Cell)

· Discharge Cut-off Voltage: 41.6V (Pack) / 2.6V (Cell)

· Built-in Integrated Battery Management System (BMS)

· Dimension: 410 × 280 × 180 mm
