130W (1160*540*30mm) Double-sided Solar panel

Dimensions : 1160x540x30mm

Weight : 6.5 kg

Nominal Power: 130W

Maximum Power Voltage: 20.42V



Advantages:

1. The efficiency of high-quality and high-efficiency monocrystalline silicon wafers can reach 22%.

2. Double-sided solar panels greatly increase the power of the components.

3. Using tempered glass, high transparency.

4. Anti-corrosion EVA effectively protects the battery panel.

5. Strong and anti-wind and snow, unique technology to avoid freezing of water in the frame and deformation.

6. Lightweight and flexible features can make it seamlessly integrated into your vehicle.

7. Packed in a single carton, with protective corners on all four corners.

8. OEM and ODM supported.


Scope of application:

Prevent the loss of electricity: used on the roof of the car, charge the car battery at any time. Can prevent the car battery from losing electricity, and solve the situation that the car cannot be fired due to the battery loss caused by the long-term parking of the vehicle.

On-board electrical appliances: when using on-board electrical appliances, the original power of the car battery will not lose (car audio, navigator, driving recorder, exhaust fan, car blower, car refrigerator, cell phone, etc.)

Experimental power generation: DIY experiments for schools.

微信图片_20241126142333.png?27


Model numberSZ-130-36M
Nominal Power130W
Maximum Power  Current6.37A
Maximum Power Voltage20.42V
Open-circuit Voltage24.27V
Short-circuit Current6.75A
Maximum System Voltage500V
Output Tolerance0~+3%
Cable MC4700mm / 2.5mm²
Module StructureAluminum Frame / Glass / EVA /Backsheet
Junction box rating≥IP67
Cell166*31.4–36*3
Working Temperature-40~+80℃
Module Dimensions1160*540*30mm
WeightNet /Gross6.5kg/7.4kg
