NEW 300W B-Portable Folding Solar Panel SOLARFAM

Dimensions : Folded 580x580x70mm

Weight : 9.3 kg

Nominal Power: 300W

Maximum Power Voltage: 17.4V



Advantages:

The conversion rate of high-efficiency solar cells is as high as 22%;

Intelligent compatible interface. USB-A, 5V2A; Cell phone& computer charger-B, 5V3A;

Used to charge cell phones, laptops, or other USB charging devices.

Equipped with the supporting stand, it can directly face the sun and charge the device.

Foldable design, handbag shape, stylish and generous, easy to carry. An ideal choice for camping, hiking, and other outdoor activities.

OEM and ODM supported.

Scope of application:

Prevent the loss of electricity: used on the roof of the car, charge the car battery at any time. Can prevent the car battery from losing electricity, and solve the situation that the car cannot be fired due to the battery loss caused by the long-term parking of the vehicle.

On-board electrical appliances: when using on-board electrical appliances, the original power of the car battery will not lose (car audio, navigator, driving recorder, exhaust fan, car blower, car refrigerator, cell phone, etc.)

Experimental power generation: DIY experiments for schools.


Model NumberSZ-300-FC-B
Nominal Power300W
Maximum Power Voltage17.4V
Maximum Power Current17.25A
Open-circuit Voltage20.4V
Short-circuit Current18.28A
Output Tolerance0~3%
Cell182*91*5*3*6
DC OutputXT60 / 30A (Max.)
USB-C PD3.05-20V / 3A; 20V5A (Max.)
USB Port-A5V2A
USB Port-QC3.05-20V/3A
Working Temperature -20~+65
Module Dimensions (Folded) 580*580*70mm
Module Dimensions (Unfolded)3200*580*30mm
Weight(Net /Gross)9.3/10.0kg
Cable 1*XT60 to MC4—2.5mm²-1.5m
